50-60T Tipper Semi Trailer 3 Axles Blue

Name: 50-60T Tipper Semi Trailer 3 Axles Blue
Brand: CHINA NATIONAL HEAVY DUTY INDUSTRY GROUP LIMITED
SKU: LML9400GYY
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: SINOTERCEL

Certification: ISO/3C/SGS/BV

Model Number: LML9400GYY

Payment & Shipping Terms

Minimum Order Quantity: 1unit

Price: Negotiable

Packaging Details: waxing

Delivery Time: 25 working days

Payment Terms: T/T

Supply Ability: 1000units/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                    50-60T tipper semi trailer, 3 axles tipper semi trailer, blue tipper semi trailer


Hydraulic:	Hydraulic System	Thickness:	Side Wall:8 Mm; Bottom Floor:10 Mm
Overall Length:	7500 Mm	Kingpin:	JOST Bolt In King Pin
Feature:	Heavy Duty	Bottom Plate:	8mm

Hydraulic:	Hydraulic System
Thickness:	Side Wall:8 Mm; Bottom Floor:10 Mm
Overall Length:	7500 Mm
Kingpin:	JOST Bolt In King Pin
Feature:	Heavy Duty
Bottom Plate:	8mm

50-60T Tipper Semi Trailer 3 Axles Blue

50-60T Tipper Semi Trailer 3 Axles Semi Flatbed Trailers Blue

Product Description:

Product features of low flat transport semi-trailer:
The load-carrying surface of the cargo platform of the frame is low, which is suitable for the transportation of various construction machinery and large-scale equipment. It is widely used, efficient and fast.
Reasonable structure: The whole vehicle is optimized by advanced computer-aided design system, and the frame adopts a frame structure combining penetrating beams and I-shaped beams, which has high strength, good rigidity and toughness.
Advanced technology: The longitudinal beam is made of low-alloy steel specially used for automobiles and welded by a fully automatic buried welding machine. The parts of the frame are all shot blasted to enhance the paint adhesion and weather resistance, making the vehicle beautiful and practical.
Suspension system: The tandem independent balance suspension system is adopted to ensure the load balance of each axle.

Parameter:

Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
Model	3 Axles 60Tons
Axle	FUWA brand, 16ton, 3 Sets
Cargo Body	1050023001500mm, floor:10mm, side:6mm
Material	Carbon steel or Mn steel
Gross vehicle weight	75000kgs
King pin	#90
Support leg	JOST Standard 28T
Suspension	Normal suspension
Thickness leaf spring	10/10/10
Tire/Rim	1200R20, 13pcs, 8.5, 12 pcs
Brake Chamber	Standard 6 pcs
Spare wheel carrier	2 pcs
Tool box	1 pcs
Electrical System	Chinese standard 24C lighting system
Side Maker Lamp	LED lamp
Painting	Polyurethane Paint
Overall dimension	12000×2500×3880(mm)
Color	White, red, green, golden and so on.
Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
